项目Specification |
Unit |
CV1000ATC |
CV1250ATC |
CV1600ATC |
CV2000ATC |
CV2500ATC |
|
盘面直径 Table Diameter |
mm |
1000 |
1250 |
1600 |
2000 |
2500 |
|
***回转直径 Max. Swing Diameter |
mm |
1350 |
1600 |
2000 |
2500 |
3000 |
|
***切削直径 Max. Cutting Diameter |
mm |
1100 |
1350 |
1800 |
2300 |
2800 |
|
***切削高度 Max. Cutting Height |
mm |
900 |
1300 |
1300 |
1600 |
1600 |
|
***切削重量 Max. Cutting Weight |
Kg |
4000 |
5000 |
8000 |
10000 |
15000 |
|
***刀库载重 Max. Tool Magazine Capacity |
Kg |
600 |
||||
|
X向行程 X-Axis Travel |
mm |
-350,+700 |
-100,+850 |
-100,+1100 |
-1000,+1400 |
-900,+1600 |
|
Z向行程 Z-Axis Travel |
mm |
800 |
900 |
900 |
1200 |
1200 |
|
横梁上下行程 Crossbeam Vertical Travel |
mm |
500 |
800 |
800 |
1200 |
1150 |
|
X/Z快速进给 X/Z Rapid Traverse |
m/min |
12/10 |
12/10 |
12/10 |
10/10 |
10/10 |
|
主轴***扭矩 Max. torque of spindle |
N.m |
8496 |
8607 |
19677 |
55158 |
68849 |
|
定位精度 Positioning Accuracy |
mm |
±0.007/500 |
||||
|
重复定位精度 Repeatability Accuracy |
mm |
±0.005 |
||||
|
占地 Floor Space |
mm |
4000*4800 |
4600*5200 |
5550*5530 |
6850*4650 |
7550*5130 |
|
机床高度 Machine Height |
mm |
4850 |
5400 |
5400 |
6270 |
6650 |
|
重量 Weight |
Kg |
20000 |
22000 |
24000 |
49000 |
55500 |
立式车削中心系列
